✅ Highly efficient oil-air separation results in low residual oil content in compressed air, reducing the load on downstream precision filter elements. ✅ The filter media is highly durable; it resists bulging under high-pressure conditions and prevents oil leakage, thereby reducing lubricant consumption. ✅The pressure drop increases gradually, preventing excessive internal pressure loss in the air compressor. ✅ Ensures clean compressed air for downstream applications, protecting the proportional valves and cutting lenses of laser machines and reducing the risk of malfunctions.
Specifications:
- Compatible Model: Dehaha 15kW Screw Air Compressor - Air Flow Rate: 2.0 m³/min - Maximum Operating Pressure: 16 bar - Operating Temperature: ≤120°C - Residual Oil Content in Exhaust Air: ≤3 ppm - Filter Media: Ultra-fine glass fiber composite filter media - Initial Pressure Drop: ≤0.02 MPa - Design Life: 4,000–6,000 h
